Gratus 3 Ton Duct Type Air Conditioner | T3 Tropicalized | Heavy-Duty Cooling | SD38TRAC4
Model SD38TRAC4 Duct AC
Availability on enquiry
1 Year
The Gratus SD38TRAC4 3 Ton Duct Type Air Conditioner is engineered for powerful commercial and residential cooling. Featuring T3 tropicalized performance, multiple protection systems, automatic ESP self-adaption, double anti-corrosion technology, and operation up to 55°C, it delivers reliable, energy-efficient cooling in demanding environments.
- 3 Ton Cooling Capacity
- 34,500 BTU/h T1 Cooling Capacity
- 30,500 BTU/h T3 Cooling Capacity
- Self-Adaption Technology
- Up to 55°C T3 Operation
Sales support
Price on enquiry
Get current pricing, availability and delivery support from the Gratus team.
Description
The Gratus SD38TRAC4 3 Ton Duct Type Air Conditioner is designed to provide powerful and consistent cooling for villas, offices, retail spaces, restaurants, and commercial buildings. Built for T3 tropical climate conditions, it delivers dependable performance even in extreme ambient temperatures of up to 55°C.
Its Automatic ESP Self-Adaption Technology intelligently adjusts airflow according to the ducting system, ensuring optimal air distribution, improved comfort, and quieter operation without manual adjustments.
To ensure long-term reliability, the unit features Multiple Protection Systems, including high-pressure protection, low-pressure protection, compressor overload protection, overheating protection, anti-freezing protection, phase-loss and phase-reverse protection, along with intelligent sensor fault detection and error code display.
Designed for installation flexibility, the Flexible Air Intake Design supports rear air intake as standard, while the bottom air intake option allows easy adaptation to different building layouts and installation requirements.
The outdoor unit is protected by Double Anti-Corrosion Technology, featuring galvanized metal construction with premium powder coating to withstand humidity, salt-laden air, and harsh outdoor environments, making it ideal for Gulf weather conditions.
With its durable construction, advanced protection features, and energy-efficient performance, the Gratus SD38TRAC4 is the ideal cooling solution for demanding commercial and residential applications.
Specifications
- Model: SD38TRAC4
- Type: Duct Type Air Conditioner
- Cooling Capacity (T1): 34,500 BTU/h
- Cooling Capacity (T3): 30,500 BTU/h
- Compressor Type: Rotary
- Operating Condition: T3
- Maximum Ambient Temperature: Up to 55°C
- Power Supply: 220–240V~, 50Hz, 1Ph
- Cooling Power Input (T1/T3): 2.88 / 3.50 kW
- Indoor Unit Dimensions (W × D × H): 1250 × 735 × 290 mm
- Indoor Unit Packaging Dimensions: 1430 × 800 × 360 mm
- Indoor Unit Net/Gross Weight: 57 / 64 kg
- Piping Size: DN20 (R3/4)
- Outdoor Unit Dimensions (W × D × H): 970 × 395 × 803 mm
- Outdoor Unit Packaging Dimensions: 1105 × 495 × 895 mm
- Outdoor Power Supply: 220–240V~, 50Hz, 1Ph
- Installation Type: Concealed Duct / Ceiling Installation
- Air Intake: Rear Standard / Bottom Optional
- Outdoor Housing: Galvanized Metal with Powder Coating
Features
- 3 Ton Cooling Capacity
- 34,500 BTU/h T1 Cooling Capacity
- 30,500 BTU/h T3 Cooling Capacity
- Self-Adaption Technology
- Up to 55°C T3 Operation
- Concealed Duct Installation
- Flexible Rear/Bottom Air Intake
- Multiple Protection System
- High & Low-Pressure Protection
- Compressor Overload Protection
- Overheating Protection
- Anti-Freezing Protection
- Phase-Loss & Phase-Reverse Protection
- Sensor Failure Alert & Error Code Display
- Double Anti-Corrosion Technology
- Galvanized Metal Outdoor Housing
- Advanced Powder-Coated Finish
- Optimized Airflow
- Low-Noise Operation
Warranty supportOfficial Gratus assistance.
Delivery guidanceHelp with UAE delivery options.
Installation helpSupport after purchase.
Customer careFast product enquiry response.
Technical specifications
View full specificationsWarranty1 Year
Features
- 3 Ton Cooling Capacity
- 34,500 BTU/h T1 Cooling Capacity
- 30,500 BTU/h T3 Cooling Capacity
- Self-Adaption Technology
- Up to 55°C T3 Operation
- Concealed Duct Installation
- Flexible Rear/Bottom Air Intake
- Multiple Protection System
- High & Low-Pressure Protection
- Compressor Overload Protection
- Overheating Protection
- Anti-Freezing Protection
- Phase-Loss & Phase-Reverse Protection
- Sensor Failure Alert & Error Code Display
- Double Anti-Corrosion Technology
- Galvanized Metal Outdoor Housing
- Advanced Powder-Coated Finish
- Optimized Airflow
- Low-Noise Operation
Gratus 3 Ton Duct Type Air Conditioner | T3 Tropicalized | Heavy-Duty Cooling | SD38TRAC4
The Gratus SD38TRAC4 3 Ton Duct Type Air Conditioner is designed to provide powerful and consistent cooling for villas, offices, retail spaces, restaurants, and commercial buildings. Built for T3 tropical climate conditions, it delivers dependable performance even in extreme ambient temperatures of up to 55°C.
Its Automatic ESP Self-Adaption Technology intelligently adjusts airflow according to the ducting system, ensuring optimal air distribution, improved comfort, and quieter operation without manual adjustments.
To ensure long-term reliability, the unit features Multiple Protection Systems, including high-pressure protection, low-pressure protection, compressor overload protection, overheating protection, anti-freezing protection, phase-loss and phase-reverse protection, along with intelligent sensor fault detection and error code display.
Designed for installation flexibility, the Flexible Air Intake Design supports rear air intake as standard, while the bottom air intake option allows easy adaptation to different building layouts and installation requirements.
The outdoor unit is protected by Double Anti-Corrosion Technology, featuring galvanized metal construction with premium powder coating to withstand humidity, salt-laden air, and harsh outdoor environments, making it ideal for Gulf weather conditions.
With its durable construction, advanced protection features, and energy-efficient performance, the Gratus SD38TRAC4 is the ideal cooling solution for demanding commercial and residential applications.
Technical specifications
- Model: SD38TRAC4
- Type: Duct Type Air Conditioner
- Cooling Capacity (T1): 34,500 BTU/h
- Cooling Capacity (T3): 30,500 BTU/h
- Compressor Type: Rotary
- Operating Condition: T3
- Maximum Ambient Temperature: Up to 55°C
- Power Supply: 220–240V~, 50Hz, 1Ph
- Cooling Power Input (T1/T3): 2.88 / 3.50 kW
- Indoor Unit Dimensions (W × D × H): 1250 × 735 × 290 mm
- Indoor Unit Packaging Dimensions: 1430 × 800 × 360 mm
- Indoor Unit Net/Gross Weight: 57 / 64 kg
- Piping Size: DN20 (R3/4)
- Outdoor Unit Dimensions (W × D × H): 970 × 395 × 803 mm
- Outdoor Unit Packaging Dimensions: 1105 × 495 × 895 mm
- Outdoor Power Supply: 220–240V~, 50Hz, 1Ph
- Installation Type: Concealed Duct / Ceiling Installation
- Air Intake: Rear Standard / Bottom Optional
- Outdoor Housing: Galvanized Metal with Powder Coating
